Leviton 600 - Appendix B Specifications; Console Specifications

User Guide Appendix B Specifications
Rev. 1.30.03.07.r1 Page 229
Appendix B Specifications
Console Specifications
Model 24/48 48/96 72/144 600
(Innovator Only)
Channel Faders: 48 96 144 N/A
Conventional
Channels: 384 384 384 600
Device Channels: 512 512 512 512
Submaster Faders: 24 Faders with 8 pages ofMemory(192 total).
Dimmers: 1,536 dimmers on 3 DMX Universes.
Maximum Cues: 600 cues per show.
Maximum Groups: 500 groups per show.
Maximum Macros: 500 macros per show.
Maximum Effects: 600 effects / 100 steps per effect / 9,999 steps total
The upper limit of cues, groups, macros and effects is user changeable to
maximize memory usage.
Environmental
• Operating Temperature: +5 °C to +40°C (+40°F to +104°F)
• Non-operating Temperature: -25°C to +65°C (-13°F to +150°F)
• Operating Humidity: 20 - 80% non-condensing
• Non-operating Humidity: 10 - 85% non-condensing
Standards Compliance
• USITT DMX 512-1990 dimmer protocol (except pins 4 & 5)
• Underwriters Laboratories (UL and C-UL) listed
Power Requirements
• 100 - 130 VAC, 50 - 60 Hz or 220 - 240 VAC, 50 - 60 Hz
• 200 watts (max) (console only - no monitor or options plugged in)
