User Guide Chapter 9 Patching
Rev. 1.30.03.07.r1 Page 139
Custom Patching Channels to Dimmers
You can create a custom patch by pressing the number of the channel that
you want to assign, followed by the [DIMMER] key. At this point, you can
enter dimmer number assignment(s).
Follow these example steps to patch channel 2 to dimmer 5 at full:
Procedure: Notes:
1. Press [PATCH] Opens Patch display
2. Enter [2] on keypad Selects channel 2 for patching
3. Press [DIMMER]
4. Enter [5] on keypad Selects dimmer 5
Use the [AND], [MINUS]
and [THRU] keys for multiple
dimmers.
5. Press [ENTER] Command line reads:
"Channel 2 To Dimmer 5"
In all patching commands, it is not necessary to specify channel
numbers with a channel key. The console automatically assumes that
the channel is addressed in the first part of the command and the
dimmer in the second part, unless the [DIMMER] key is pressed first.
