Appendix A Installation
Page 228 Rev. 1.30.03.07.r1
Configuration
If you are not familiar with the Setup Display of the control console, you
may wish to refer to
Chapters 12 System Settings
for an overview before
proceeding. Also refer to
Chapter 2 Displays
for information on how to
switch active monitors.
To configure the operation of the Secondary Video option:
Procedure: Notes:
1. Press [SETUP] Opens Setup display
2. Press [22] Menu Item 22: Disabled
3. Press [ENTER]
4. Using the up/down arrow keys to
select mode (see Monitor Modes below)
5. Press [ENTER]
Monitor Modes
Disabled: Use this selection when you are using only one monitor.
Auto Switch: Use this selection to activate the secondary video display
and to allow "Automatic" switching between displays when a display key is
pressed.
Man Switch: Use this selection to activate the secondary video display and
to disallow "Automatic" switching between displays when a display key is
pressed. Moving between video displays must be set by the Trackball or the
(MONITR) soft-key.
Fixed mode: This mode has eight settings corresponding to the eight
primary displays for the console. The eight settings are:
Fixed Stage Fixed Preview
Fixed Device Fixed Cuesht
Fixed Track Fixed Playbk
Fixed Patch Fixed Setup
