User Guide Chapter 4 Submasters
Rev. 1.30.03.07.r1 Page 51
Naming Submasters
You can assign names up to 16 characters in length to submasters. These
names can be exclusively numbers, exclusively letters or a combination of
letters and numbers. Names are entered using the submaster bump
buttons for letters and the keypad for numbers. You can also use a
standard PC keyboard to enter names. Please see
Appendix A
for
information on installing a keyboard.
Table 4.0 Character to Bump Button Assignments
In the above chart, the letters x and z are selected by pressing and holding
the w and y keys respectively. A space is added by pressing and holding the
v key. For uppercase letters, press and hold the Leviton Logo key while
selecting letters.
Follow the steps below to name a submaster:
Procedure: Notes:
1. Press [PREVIEW]
2. Press (SelSub) [#] [ENTER] Enter the number of the sub
to be named
3. Press (Name)
4. Enter a name Use Sub Bump Buttons or
PC keyboard
5. Press [ENTER]
Bump
Button
Alpha
Character
Bump
Button
Alpha
Character
Bump
Button
Alpha
Character
1a9i 17q
2b10j 18r
3c11j 19s
4d12l 20t
5e13m21u
6f 14n22v (space)
7g15o23wx
8h16p24yz
