User Guide Chapter 10 Automated Devices
Rev. 1.30.03.07.r1 Page 151
The console is shipped with Ports A and B configured as a 1 to 1 patch
for conventional channels and dimmers. Port C is clear and configured
for automated devices. This is also the default patch configuration after
performing a hard clear. See
Chapter 9 Patching
and
Chapter 11
Memory Functions
for more information.
Follow these example steps to initially assign a device:
Procedure: Notes:
1. Press [SETUP] Opens Setup display
2. Press (Device) Enters Device Assignment
sub-display
3. Use arrow keys to highlight the
desired device number
4. Press [1] or [ENTER] Device menu item 1:
"Edit Assignment". Opens
device library menu.
5. Scroll device library menu using
up/down arrow keys to select device
6. Press [ENTER] to complete selection
If your device is not listed in the device library, you may need to add a
new Device Definition. Refer to the
Device Definition Language
section
later in this chapter.
