User Guide Appendix B Specifications

Rev. 1.30.03.07.r1 Page 231

Interfaces

Connector

Parallel printer port 25 pin D

DMX Out data universes (3) 5 pin XLR and (1) 3 pin XLR

DMX In (1) 5 pin XLR

MIDI In/Out/Thru (3) 5-pin DIN

Single video monitor (standard) High density 15-pin D

Second video monitor (optional) High density 15-pin D

Hand Held Remote (optional) 6-pin XLR

8 external Macro Inputs 9 pin D

Worklights 3 pin XLR or BNC depending on model

Ethernet RJ 45, AUI (Innovator Only)

Keyboard 5 pin DIN

Warranty

• Two year Warranty (see inside front cover)

• Free software upgrades during warranty period

Part Numbers

Description

Cat. No.

Innovator 24/48 7-0048

Innovator 48/96 7-0096

Innovator 72/144 7-0144

Innovator 600 7-0600

MC 24/48 (120 Volt) N2448-000

MC 24/48 (240 Volt) N2448-009

For Accessory information and part numbers, please consult

Console Data Sheet.
