Repair information 4-5
5026
27S2837 M3.5X1.34 panhead
8L, black
Left cover to lower frame 2
Rear left cover through lower swingout frame into left cover 1
Rear right cover to rear upper cover 1
Rear upper cover to top cover 1
Top cover to right cover 1
27S2838 Machine M3X0.5–
6GL
Contacts assembly to left/front edge of printer frame 2
Fax modem blank plate to left plate 1
ISP blank plate to left plate 2
Second USB connector to left frame 1
System board USB connector to frame 1
USB-A Blank plate to left plate 1
27S2839 Taptite M3 L6
Taptite slotted hex
black
Rear cover frame to frame 8
88A0003 Machine M3X0.5-
6G 8L
Printhead 3
88A0095 M2.5x10 Machine 5 V interlock switch actuator assembly 1
24 V interlock switch and shield to right frame 1
88A0212 Taptite M3.5x0.6
PAN
Fuser AC cable's ground wire to left plate 1
88A0232 Taptite M3 L6
PANHD
Cartridge right guide assembly to rightside plate 10
Lower plate to lower swingout frame assembly 1
Lower swingout frame assembly to left frame assembly 4
Lower frame support to right frame assembly 4
88A0233 Taptite M3 L8
PANHD
Lower swingout frame assembly to leftside frame assembly (rearmost
position)
1
Screw identification table (continued)
P/N Screw type Location Qty
To Next Page
