Issue 5 November 2000
363-206-208
Powering, Verification, and Circuit Pack Installation for the DDM-2000 OC-12 Multiplexer
Lucent Technologies - Proprietary
See Notice on first page
(5) Use the appropriate MS-DOS
†
command (for example, a: or b:) to go to the drive
where the diskette is installed.
(6) Enter the “term” command and press the RETURN (or ENTER) key twice on
the PC. Observe for the following response:
CTRM ready. (Type Alt-h for help.)
(7) Connect the PC to the CIT connector on the front of the shelf user panel.
(8) Enter a question mark(
?) or press the RETURN key.
Response:
/* Enter a shelf number from 1 to 8*/
shelf [default] =
(9) Enter a question mark(
?) or press the RETURN key.
Response: In Progress .....
(10)The software download is in progress as indicated by the series of dots follow-
ing the In Progress message and will continue while the software is down-
loading.
(11) If the software is contained on more than one diskette, a prompt will be printed
when the next diskette is required. Remove the existing diskette and insert the
next one.
(12)After completion of download, the message: ins-prog: TID COMPLD will
appear.
(13)Repeat the download procedure for all spare BBG5 SYSCTL and BCP1 OHCTL
circuit packs.
Releases 5 and 7 Software Download Procedure
NOTE:
If there are any unpowered DDM-2000 shelves in the bay that have craft inter-
face terminal (CIT) multed to this DDM-2000 OC-12 shelf, verify that the BBG8
SYSCTL circuit packs in the unpowered shelves are not fully seated in their shelf
slots.
(1) Fully insert the BCP4 OHCTL circuit pack into the shelf. The FAULT LED on the
circuit pack will light.
(2) Fully insert the BBG8 SYSCTL circuit pack into the shelf.
† Registered trademark of Microsoft Corporation
