Lucent Technologies DDM-2000 OC-12 Installation Manual

Issue 5 November 2000 
363-206-208
Powering, Verification, and Circuit Pack Installation for the DDM-2000 OC-12 Multiplexer
Lucent Technologies - Proprietary
See Notice on first page
SYSCTL Switch 2 Note:
* Only site addresses 1-8 are supported prior to Release 2.1 (linear) and Release 3.0 (ring). For
prior Releases, Switch 2 sections 7 and 8 must be set to the ON position as indicated.
Figure 5-3 (Continued). BBG5 SYSCTL Option Switches (Sheet 3 of 4)
Switch 2 Settings
Site Address Shelf ID Number
Value Sec 1 Sec 2 Sec 3 Sec 7 Sec 8 Value Sec 4 Sec 5 Sec 6
1 ONONONONON1 ONONON
2 OFF ON ON ON ON 2 OFF ON ON
3 ON OFF ON ON ON 3 ON OFF ON
4 OFF OFF ON ON ON 4 OFF OFF ON
5 ONONOFFONON5 ONONOFF
6 OFF ON OFF ON ON 6 OFF ON OFF
7 ONOFFOFFONON7 ONOFFOFF
8 OFF OFF OFF ON ON 8 OFF OFF OFF
9 ONONONOFFON
10 OFFONONOFFON
11 ON OFF ON OFF ON
12 OFF OFF ON OFF ON
13 ON ON OFF OFF ON
14 OFF ON OFF OFF ON
15 ON OFF OFF OFF ON
16 OFF OFF OFF OFF ON
17 ON ON ON ON OFF
18 OFFONONONOFF
19 ON OFF ON ON OFF
20 OFF OFF ON ON OFF
21 ON ON OFF ON OFF
22 OFF ON OFF ON OFF
23 ON OFF OFF ON OFF
24 OFF OFF OFF ON OFF
25 ON ON ON OFF OFF
26 OFFONONOFFOFF
27 ON OFF ON OFF OFF
28 OFF OFF ON OFF OFF
29 ON ON OFF OFF OFF
30 OFF ON OFF OFF OFF
31 ON OFF OFF OFF OFF
32 OFF OFF OFF OFF OFF
