Manitowoc GROVE GMK5150L

Operating elements for crane operation
9.2 Short description of the operating elements
Operating manual 9 - 121
GMK5150L
CCS display
Power units display
High-speed mode inspection derricking gear
Side panel
– Green: Derricking gear on
–Red: Derricking gear off
–On: High-speed mode on
–Out: High-speed mode off
à p. 11 - 113
1 Raise enable button after RCL shutdown
RCL override – version A;
à p. 9 - 143.
RCL override – version B;
à p. 9 - 144.
