Operating elements for driving
3.1 Overview of the operating elements
Operating manual 3 302 709 en 3 - 3
GMK5150L
12.01.2018
s
1 Front flap à p. 3 - 73
2 Driver's cab
à p. 3 - 6
3 Hose drum, installing/removing
1), 2)
4 Engine for driving à p. 4 - 1
5 Rigging the main boom
1),
à p. 6 - 17
6 Auxiliary hoist Operation
1)
Rigging the auxiliary hoist
1)
à p. 9 - 116
à p. 6 - 39
7 APS connection/interface
(Auxiliary Power Supply)
1), 3)
8 – Spare wheel
1)
– Towbar coupling
1)
– Third brake light – At the rear of carrier/storage
compartment
1)
– Third brake light – At the spare wheel clamp
1)
à p. 8 - 33
à p. 5 - 81
à p. 5 - 12
à p. 8 - 35
9 BirdView system 270° – Camera
1)
à p. 3 - 53
10 Chocks
1)
à p. 5 - 46
11 Storage space for the folding ladder
à p. 3 - 77
12 Outriggers
– Operation
– Lighting
– Installing/removing the outrigger beams
à p. 12 - 41
à p. 12 - 45
à p. 6 - 51
13 Swing-out ladders
à p. 3 - 77
14 – Fuel tank
– Dual tank
1)
à p. 4 - 5
à p. 4 - 6
15 – Outrigger control units
– Emergency stop switch
à p. 3 - 38
à p. 4 - 19
16 Step at the crane cab Switching on/off
à p. 12 - 157
1)
Additional equipment
2)
à Lattice extension operating manual
3)
à Separate operating manual
