Estop Switch
An Estop switch is important and MASSO will not work without one. Please ensure you have your Estop
connected.
EStop Wiring
Hint: How the Estop switch is wired will depend on whether you have a pendant or not.
WARNING: E-Stop wiring must be done as per your country or region's safety regulation. MASSO
will put the machine in feedhold and stop spindle on E-Stop press but all drives and actuators
MUST be disabled directly by E-Stop signal from the E-Stop button. MASSO's E-Stop input is only
designed to alert the user that the an E-Stop has been pressed.
Hint: When Estop is pressed the axis will decelerate to a stop. If an instant stop is wanted on your
drives you need to wire the drive’s enable circuit through an Estop Relay contact. A TTL output
called ES is provided to allow you to connect a TTL relay which will release when the Estop is
pressed. This can be used to stop external hardware. eg. VFD disable, disable motor drives etc.
Additional resource video
