Scan the QR code to watch the MASSO video tutorial on YouTube
Or, Click here to view the video
Axis configuration
Axis calibration instructions
Distance per revolution: How far your axis travels in one revolution of the motor.
Pulses per revolution: How many steps it will take for your motor to complete 1 revolution
Maximum feedrate: Defines your axis rapid speed.
Acceleration setting: Determines how quickly your axis accelerates to your chosen feedrate.
Travel Minimum: This value determines the extent of travel for the axis in the negative direction
Travel Maximum: This value determines the extent of travel for the axis in the positive direction
Invert direction: If your axis travels in the wrong direction, put a check in this box to reverse it.
Backlash: Enter your axis backlash. Note that it must not exceed 10mm or 0.3937”
Hint: The biggest mistake new users make is to ignore the maximum and minimum travel setting.
If you leave these at 0 your axis will not move as these form part of MASSO soft limit system.
Please note that disabling soft limits under general settings only disables them while machining but
you are still bound by them when it comes to jogging your axis. It is recommended that you enter
very large maximum and minimum values into your axis until you are ready to properly configure
them. That way you will be able to jog around your table without running into a limit. The Maximum
travel MUST be larger than the Minimum travel value or the axis will move in one direction only.
Rotary Axis
For information on how to setup and calculate a rotary axis please see the Quick Start guide on setting up a
v5.18 - 08 Apr,2021
www.masso.com.au Page 155 of 477
