MASSO
MASSO Documentation
Rotary Axis
Setting up a Rotary Axis
Jogging
Keyboard key shortcuts page
To jog your machine you must be in the F3 Jogging screen.
Jogging can be done on the F3 screen with either Mouse, Touch screen, Keyboard or Pendant.
If you cannot Jog use the Mouse to click the jog buttons as users have had issues with faulty
Keyboards, pendants and touch screens in the past. Using the mouse is the best test for jogging.
Hint: If the Axis DRO is not showing movement then the physical axis will not move. Please check
your Axis settings above and especially your minimum and maximum travel values. If you reach a
travel limit the button will turn red and the word Limit will be displayed on the button to let you
know.
Hint: If your axis does not move check that you do not have a value of 0 in any of the following
settings: Motor: Distance per revolution, Drive: Pulses per revolution, Maximum feedrate or
Acceleration. Leaving a value of 0 in any of these 4 parameters on any axis will cause issues. If
you are not using an axis please configure it with dummy values.
v5.18 - 08 Apr,2021
www.masso.com.au Page 156 of 477
