INFORMATION: From MASSO software v3.48, if "Tool Changer - Output 2" is not assigned as
an output in F1-Setup screen then the 6 second delay is automatically ignored by the logic.
Tool Changer logic
When a tool change command is received, the tool changer logic works in the followings steps:
1. Spindle is turned OFF and system waits for the spindle to stop as per the spindle "Spin down
delay" value in the spindle settings.
2. System checks if the current tool in the spindle is setup in a slot is the F4-Tools screen, else gives
an error.
3. System checks if the tool to load is setup in a slot is the F4-Tools screen, else gives an error.
4. Z Axis moves up to the homing position.
5. "Tool Changer - Output 1" goes HIGH to move Dust Hood UP, then system waits for 6 seconds for
the "Tool Changer - Input 3" (Dust Hood UP OK) signal to go HIGH, else gives an error.
6. X & Y Axis moves to tool unload position.
7. Z Axis moves down to the tool unload position.
8. "Chuck Clamp M10/M11" goes HIGH to unclamp the tool, then system waits for 6 seconds for the
"Tool Changer - Input 1" (Spindle draw bar Status) signal to go HIGH, else gives an error.
9. Z Axis moves up to the tool unload clearance position.
10. X & Y Axis moves to new tool load position.
11. Z Axis moves down to the tool load position.
12. "Chuck Clamp M10/M11" goes LOW to clamp the tool, then system waits for 6 seconds for the
"Tool Changer - Input 1" (Spindle draw bar Status) signal to go LOW, else gives an error.
13. Axis moves to slide out the new tool.
14. Z Axis moves up to the homing position.
15. "Tool Changer - Output 1" goes LOW to move Dust Hood DOWN, then system waits for 6 seconds
for the "Tool Changer - Input 3" (Dust Hood UP OK) signal to go LOW, else gives an error.
16. "Tool Changer - Output 2" goes HIGH for 6 seconds (For spindles with air return requirement).
INFORMATION: From MASSO software v3.48, if "Tool Changer - Output 2" is not assigned as
an output in F1-Setup screen then the 6 second delay is automatically ignored by the logic.
INFORMATION: All input & output signals can be easily inverted by selecting the input or output in
the list and pressing the space-bar key on the keyboard to invert the signal. These settings are
automatically saved.
INFORMATION: Make sure to assign each tool into a tool slot in the F4 - Tools & Work offset
screen else on a tool change command if the tool is not set in a slot you will get a tool error alarm.
v5.18 - 08 Apr,2021
www.masso.com.au Page 409 of 477
