added to the slot position coordinate value.
You can use positive or negative values to determine which side of the tool holder you approach
from.
The values are defined in the native unit of measurement, either metric or imperial that you have set
under general settings in the F1 Screen.
Defining the Tool Position
The Center of each slot is defined by the Slot #: X, Y position parameter box.
These coordinates used to define the tool position and are Machine coordinates.
The values are defined in the native unit of measurement, either metric or imperial that you have set
under general settings in the F1 Screen.
Because each tool holder's position is defined by both an X & Y coordinate you can place the tools
anywhere on the table but be aware that if you are using a slide in the tool holder.
When using a Pick and place tool holder you can define multiple rows of tools.
INFORMATION: Tool slot coordinates can be located outside of the machine's soft limits.
Coordinate Calculations
Calculate coordinate positions as follows:
Tool clearance offset coordinate X, Y = Slot position X + Tool clearance offset position X, Slot
position Y + Tool clearance offset position Y
Tool change offset coordinate X, Y = Slot position X + Tool change offset position X, Slot position
Y + Tool change offset position Y
Example: 1
