68 Chapter 7: Navigation
PRO Series Live Audio Systems
Owner’s Manual
You can use the GUI menu to select any output channel you want via the
home
Mix & Outputs option.
>> To select a processing area
You may want a specific processing area of an output channel assigned to the local
channel strip, for example, to carry out processing or for copying its parameters to
another output channel. To do this, provided the output channel is currently selected at
the control surface, press the quick access button local to the desired channel strip’s
processing area to select it.
You can select a processing area via the GUI by clicking on a non-control area within
the desired section of the ‘overview’ display (aux send, aux return, matrix or master) in
the GUI channel strip.
Navigation via the GUI
The GUI has unique navigational tools by which to return to a channel ‘overview’ display
from one of its processing areas in the GUI channel strip, and also to browse through
the GUI screen display history.
>> To navigate back to a channel’s overview display from one of its processing
areas in the GUI channel strip
Click the up arrow.
>> To find a GUI screen that you recently opened
Use the back/forward browser buttons to do one of the following:
• To return to the GUI screen you have just
opened, click the back button.
• To open one of the GUI screens you have
recently visited, click the back/forward
buttons. The back button will take you back
through your browser history, while the
forward button goes the opposite way.
The back/forward buttons are similar to those on standard browsers used on any PC.
