308 Chapter 30: Inputs
PRO Series Live Audio Systems
Owner’s Manual
LCD select button
The LCD select buttons in the input fast strips
are used for input channel navigation and
group selection. They also provide useful
feedback for the user.
For more information on navigation, see
“Navigating the input channels” on page 59.
Mute, solo and safes
This section contains the MUTE and SOLO buttons, and three safe LEDs (mute safe,
auto safe and fader safe).
Mute, solo and safes for the input channels on the control surface and GUI
Item Control Function
1 MUTE button Mutes all post-processing signals exiting the channel.
In addition to scene recall, it can also be remotely
muted from the auto-mute masters.
2 SOLO button Activates signal routing to the monitor A section of
the control centre by sending the input channel signal
to PFL mono and AFL stereo buses. The solo system
is auto-cancelling, so that each new solo cancels the
last one. Input solos override any active VCA solos.
This button is a latching type. Give a short press to
latch it and a long press to self-connect when it is
released.
3 B button This solo button (GUI only) changes the operation of
the SOLO switch so that it routes signals to the
monitor B section of the control centre.
