Controlling an internal effect via the I zone 193
PRO Series Live Audio Systems
Owner’s Manual
>> To change the I zone control assignments
Click the left/right arrow button.
In view 2/4 of the 3-band compressor effect the I zone is assigned to the Mid section.
Clicking the right arrow takes you to view 3/4, and the I zone is now assigned to the
Hi section. If you clicked the left arrow instead, this would take you in the opposite
direction to view 1/4, and the I zone would be assigned to the Lo section.
>> To change to another device in the rack
Click the up/down arrow button. This will open the next device (effect/GEQ) in the
device window. If there is no device assigned to the newly opened rack position, the
device window will be empty.
Controlling an internal effect via the I zone
When controlling an effect, the GUI shows the current button and control knob I zone
assignments.
>> To operate a button of an effect
1 Make sure that the effect’s button you want to operate is assigned to the I zone.
If necessary, navigate the effects page containing the desired button to the
I zone. (The text at the top of the LCD button indicates its assignment.)
2 Press the desired I zone button.
>> To operate a control knob of an effect
1 Make sure that the effect’s control knob you want to operate is assigned to the
I zone. If necessary, navigate the effects page containing the desired button to
the I zone.
2 Adjust the desired control knob.
