552 Appendix O: Parameters Affected By Stereo Linking

PRO Series Live Audio Systems

Owner’s Manual

Direct output

Not applicable.

Direct input

The following diagram shows the direct input control parameters that are linked across

the channel pair.

Filters

Not applicable.

Item Control Parameter

1 Control knob Direct input level

2 B switch Direct input solo B on/off

3 PRE switch Direct input pre- in/out

Compressor

processing area in

GUI channel strip

aux send

overview in GUI

channel strip
