Monitor mix
The following table shows the delay compensation settings for this mix.
The following signal path examples all measure the same latency of 243 samples at
96kHz = 2.53ms:
• FOH XLR – IP – MAST – XLR
• XLR – IP – MAST – XLR
• XLR – IP – MTX – XLR
• XLR – IP – MAST – MTX – XLR
• XLR – IP – AS – XLR
• XLR – IP – AS (With GEQ) – XLR
• XLR – MAST – DI (Input) – XLR
• XLR – MTX – DI (Input) – XLR
• XLR – AS DI – AS – XLR
• XLR – AS DI – AS (With GEQ) – XLR
• XLR – AR (Input) – MAST – XLR
• XLR – AR (Input) – MAST (With GEQ) – XLR
• XLR – AR (Input) – MTX (With GEQ) – XLR
• XLR – AR (Input) – MAST – MTX – XLR
• XLR – AR (Input) – MAST – MTX (With GEQ) – XLR
• XLR – AR (Input) – AS – XLR
Option On/off status
Master to Matrix Post-processing Off
Input Channels
Insert Off
Aux Sends
Monitor Mode (Align with Masters)
Insert
Send-FZ-Return
Graphic EQ
On
Off
Off
On
Master and Matrix
Insert
Graphic EQ
Off
On
