Midas PRO SERIES User Manual

DL444 analogue D-type I/O module 387
PRO Series Live Audio Systems
Owner’s Manual
Connecting to eight XLRs
You can connect either the inputs connector or outputs connector on the rear panel of
the DL444 module to eight XLRs. To do this you will need an adapter cable with a male,
25-way D-type at one end and eight XLRs at the other.
Note: Off-the-shelf adapter cables are easily obtainable.
Although generally you will be using XLRs as terminal I/O connections, it will depend on
your rack equipment, so these could be jacks, D-types, phonos etc.
Adapter cable connections for connecting the inputs or outputs connector to eight XLRs, using the
standard “Tascam” pinout configuration.
13
1
25
14
1
1
2
3
2
1
2
3
3
1
2
3
4
1
2
3
5
1
2
3
6
1
2
3
7
1
2
3
8
1
2
3
Male socket side
25-way, male
D-type connector
Cable side
XLR
22
9
21
2
14
1
16
3
15
19
6
18
8
20
7
25
12
24
11
23
10
5
17
4
Ground
Cold
Hot
Ground
Cold
Hot
Ground
Cold
Hot
Ground
Cold
Hot
Ground
Cold
Hot
Ground
Cold
Hot
Ground
Cold
Hot
Ground
Cold
Hot
