Programming the groups 183
PRO Series Live Audio Systems
Owner’s Manual
Programming the groups
In general, you can use either the control surface or GUI to create, manage and recall
the groups. However, you might find it easier to use the GUI, as all of the channels are
available simultaneously on the screen.
>> To program a VCA/POP group at the control surface
For details, see “Using VCA/POP groups” on page 104.
>> To program a mute group at the control surface
1 In the auto mute groups section (master bay), press and hold the SELECT
button of your chosen auto-mute group.
2 Do one of the following:
• To add inputs to the group, press the LCD select button of each input channel
you want in the group. If necessary, navigate the desired input channels to
the control surface.
• To add outputs to the group, press the quick access button (bottom of each
output fast strip) of each output you want in the group. If necessary, navigate
the desired output channels to the control surface.
>> To program a VCA/POP, auto-mute or talk group at the GUI
1 At the GUI, open the screen of the desired control group type. For example, for a
VCA group open the VCA Groups screen.
2 Click the group. For example, VCA1.
3 Click the channels that you want to add to the group.
4 Click ADD. The channels will be moved to the group member panel.
If you want to remove any members from the group, click the channels that you want
to remove from the group (group member panel). Then, click REMOVE. The channels
are moved back to their respective lists.
Item Control Function
1 Group member
selection lists
These group type-dependent lists let you choose
which inputs, returns, auxes, matrices and masters
you want as members in the selected group. If
necessary, use the slider on the right of a panel to
access all non-members.
2 Name field Name of selected group.
3 Group member
panel
List of the current members of the selected group.
4 ADD button Moves the non-members (selected in the group
member selection lists) to the group member panel,
adding them to the group.
5 REMOVE button Moves the members (selected in the group member
panel) back to their respective group member
selection lists, removing them from the group.
