Midas PRO SERIES

356 Appendix B: Technical Specification
PRO Series Live Audio Systems
Owner’s Manual
PRO Series system inputs and outputs
DL251 I/O Box
Analogue inputs
Analogue outputs
MIDI
Digital system inputs and outputs
DL351 I/O Box
Analogue inputs
Analogue outputs
Digital inputs
Connector 3-pin XLR balanced
A/D converter 24-bit, 96k and 128 times over sampling
Connector 3-pin XLR balanced
D/A converter 24-bit, 96k and 128 times over sampling
MIDI connector In, out and through on 5-pin DIN
GPIO IN connector 25-pin D-type (opto isolated)
GPIO OUT connector 25-pin D-type (opto isolated)
System connector 2 x AES50 (24 channels of bi-directional digital
audio) on EtherCon® XLR
N+1 connector 1 x AES50 (24 channels of bi-directional digital
audio) on EtherCon® XLR providing redundant
back up
Connector 3-pin XLR balanced
A/D converter 24-bit, 96k and 128 times over sampling
Connector 3-pin XLR balanced
D/A converter 24-bit, 96k and 128 times over sampling
Connector AES3 (two channels of digital audio) on 3-pin
XLR
Sample rates Accepts any frequency between 32k to 96k
Bypass Sample rate converter can be bypassed
