352 Appendix B: Technical Specification
PRO Series Live Audio Systems
Owner’s Manual
PRO Series audio performance specifications
Frequency response
Gain error at 1kHz
Input Output Gain 20Hz 20kHz
DL251 I/O Box DL251 I/O Box 0dB 0dB to -1.0dB 0dB to -1.0dB
DL251 I/O Box DL251 I/O Box 40dB 0dB to -1.0dB 0dB to -1.0dB
DL351 I/O Box DL351 I/O Box 0dB 0dB to -1.0dB 0dB to -1.0dB
DL351 I/O Box DL351 I/O Box 40dB 0dB to -1.0dB 0dB to -1.0dB
Surface I/O Surface I/O 0dB 0dB to -1.0dB 0dB to -1.0dB
Surface I/O Surface I/O 40dB 0dB to -1.0dB 0dB to -1.0dB
DL451 I/O Box DL451 I/O Box 0dB 0dB to -1.0dB 0dB to -1.0dB
DL451 I/O Box DL451 I/O Box 40dB 0dB to -1.0dB 0dB to -1.0dB
DL431 Splitter DL351 I/O Box 0dB 0dB to -1.0dB 0dB to -1.0dB
DL431 Splitter DL351 I/O Box 40dB 0dB to -1.0dB 0dB to -1.0dB
DL431 Splitter DL431 A Out 0dB 0dB to -0.5dB 0dB to -0.5dB
DL431 Splitter DL431 A Out 40dB 0dB to -0.5dB 0dB to -0.5dB
DL431 Splitter DL431 B Out 0dB 0dB to -0.5dB 0dB to -0.5dB
DL431 Splitter DL431 B Out 40dB 0dB to -0.5dB 0dB to -0.5dB
DL431 Splitter DL431 C Out -6dB 0dB to -1.0dB 0dB to -1.0dB
Input Output Gain Maximum Minimum
DL251 I/O Box DL251 I/O Box 0dB +1.0dB -1.0dB
DL251 I/O Box DL251 I/O Box 40dB +1.0dB -1.0dB
DL351 I/O Box DL351 I/O Box 0dB +1.0dB -1.0dB
DL351 I/O Box DL351 I/O Box 40dB +1.0dB -1.0dB
Surface I/O Surface I/O 0dB +1.0dB -1.0dB
Surface I/O Surface I/O 40dB +1.0dB -1.0dB
DL451 I/O Box DL451 I/O Box 0dB +1.0dB -1.0dB
DL451 I/O Box DL451 I/O Box 40dB +1.0dB -1.0dB
DL431 Splitter DL451 I/O Box 0dB +1.0dB -1.0dB
DL431 Splitter DL451 I/O Box 40dB +1.0dB -1.0dB
DL431 Splitter DL431 A Out 0dB +0.5dB -0.5dB
DL431 Splitter DL431 A Out 40dB +0.5dB -0.5dB
DL431 Splitter DL431 B Out 0dB +0.5dB -0.5dB
DL431 Splitter DL431 B Out 40dB +0.5dB -0.5dB
DL431 Splitter DL431 C Out -6dB +1.0dB -1.0dB
