Pinouts for the remote status connector
Wire up the LED remote status cable as shown below. The LEDs should be suited to a
5mA current.
Pinouts for the remote status 25-way D-type chassis connector
13
12
11
10
9
8
7
1
2
3
4
5
6
14
15
16
17
18
19
25
24
23
22
21
+48V (8)
MUTE (7)
+48V (6)
MUTE (5)
+48V (4)
MUTE (3)
+48V (2)
MUTE (1)
MUTE (6)
+48V (7)
MUTE (8)
20
MUTE (4)
+48V (5)
Top
+48V (1)
MUTE (2)
+48V (3)
Rear of female D-type
socket connector
