180 Chapter 17: Control Groups
PRO Series Live Audio Systems
Owner’s Manual
For details of VCA/POP group configuration and operation, see “Using VCA/POP groups”
on page 104.
>> To select another group
With a group already selected, select another group by pressing the LCD select button
of the desired group.
>> To clear group selection
Press the LCD select button of the currently selected group.
Auto-mute (mute) groups
You can simultaneously mute any channels you want. This is done by assigning them
to an auto-mute group. You can have up to eight auto-mute groups, which are located
in the auto mute groups section (just above the primary navigation zone). A group is
muted by pressing its auto-mute button.
Auto-mute groups on the control surface and GUI
Item Control Function
1 MUTE switch Mutes/unmutes all of the assigned channels. Also,
the same channel can be assigned to more than one
auto-mute group — the channel will be auto-muted,
while any of the mute groups to which it is assigned
are muted.
2 SELECT switch Programs the auto-mute channel assignment. Shows
current assignments to auto-mute group and allows
them to be changed.
3 Name field Default and user-configured auto-mute group name.
To Next Page
