Midas PRO SERIES User Manual

PRO Series system inputs and outputs 359
PRO Series Live Audio Systems
Owner’s Manual
Analogue outputs
Digital (system) outputs
DL371 DSP/Router
System inputs and outputs
Connector A 3-pin XLR balanced
Connector B Independent second channel identical to
Connector A (above)
Connector C Independent third channel on front mounted 3-
pin XLR, balanced and transformer isolated
(with fixed gain of -6dB)
Headphone connector ¼” Jack
Audio monitor 3-pin XLR balanced
System connector A AES50 (24 channels of digital audio) on
Ethercon XLR
System connector B Independent second channel identical to
System connector A (above)
Duplicate connector A AES50 (24 channels of digital audio) on
Ethercon XLR providing dual redundant back up
of A channels
Duplicate connector B AES50 (24 channels of digital audio) on
Ethercon XLR providing dual redundant back up
of B channels
System connector 3 x AES50 (24 channels of bi-directional digital
audio) on EtherCon® XLR
N+1 connector 1 x AES50 (24 channels of bi-directional digital
audio) on EtherCon® XLR providing dual
redundant back up
System expansion connector 4 x AES50 (24 channels of bi-directional digital
audio) on EtherCon® XLR
Snake connector (copper) HyperMac (192 channels of bi-directional digital
audio) on EtherCon® XLR
Duplicate snake connector
(copper)
HyperMac (192 channels of bi-directional digital
audio) on EtherCon® XLR
Snake connector (fibre) HyperMac (192 channels of bi-directional digital
audio) on OpticalCon® XLR
Duplicate snake connector
(fibre)
HyperMac (192 channels of bi-directional digital
audio) on OpticalCon® XLR

Midas PRO SERIES Specifications

General

Series	PRO SERIES
Sample Rate	96 kHz
Word Clock	Yes
Type	Digital Mixing Console
Mix Buses	Up to 24
Connectivity	AES50
Control Surface	Motorized Faders
EQ Bands	4-band Parametric EQ per channel
Effects	Multiple internal effects engines
Frequency Response	20 Hz - 20 kHz
Processing	40-bit floating point
