556 Appendix O: Parameters Affected By Stereo Linking
PRO Series Live Audio Systems
Owner’s Manual
* Not shown in diagram.
Note: Although band 6 is not shown above, the items in the table also apply. Band 6
has items 2, 3 and 4, and also includes item 7.
Bus sends
The following diagram shows the bus sends affected by stereo linking.
Note: Although only matrix sends 1-2 are referenced above, this also applies to all
pairs of matrix sends.
7* SHAPE switch Band 6 shelving modes: bell, soft, low pass 6dB or
low pass 12dB
8 GEQ All GEQ parameters. (GEQ parameters linked
when both linked channels have a GEQ assigned to
them.)
Item Control Parameter
1 ON switch Matrix bus send on/off
2 level/pan control
knob
Bus level, or pan when bus is linked. (The pans
are not linked, only the sends levels are linked.)
3 PRE switch Pre-fader on/off
4 level control knob Bus level
Item Control Parameter
