Midas PRO SERIES User Manual

PRO Series input and output characteristics 363
PRO Series Live Audio Systems
Owner’s Manual
Digital I/O characteristics
Miscellaneous digital characteristics
Type Chan.
Data
Length I/O Description Notes Conn.
AES3 2 24-bit Input Conforms to
AES3 - 2003
XLR
AES3 2 24-bit Output Conforms to
AES3 - 2003
XLR
AES50 24 24-bit Bi-
directional
Conforms to
AES50 -2006
Ethercon
XLR
HyperMac 192 24-bit Bi-
directional
Cat 5e, Gigabit
Ethernet physical
layer
Ethercon
XLR
HyperMac 192 24-bit Bi-
directional
850 nm, laser
module 1.25Gb/s
1000 base-SX
physical layer on
50/125 multimode
fibre
Opticon
XLR
Type I/O Description Notes Connector
Word clock IN Accepts TTL level, 96kHz square
wave; impedance 75 ohms
BNC
Word clock OUT Provides a TTL level, 96kHz
square wave
BNC
AES sync IN Accepts a 96kHz digital audio
signal conforming to AES3 - 2003
XLR
AES sync OUT Provides a 96kHz grade II
reference signal conforming to
AES3 - 2003
XLR
External
(Ethernet)
- Cat 5e, Auto MDIX, 10Mb/s Fast
Ethernet physical layer
Ethercon XLR

Midas PRO SERIES Specifications

General

Series	PRO SERIES
Sample Rate	96 kHz
Word Clock	Yes
Type	Digital Mixing Console
Mix Buses	Up to 24
Connectivity	AES50
Control Surface	Motorized Faders
EQ Bands	4-band Parametric EQ per channel
Effects	Multiple internal effects engines
Frequency Response	20 Hz - 20 kHz
Processing	40-bit floating point
