Talk 319
PRO Series Live Audio Systems
Owner’s Manual
Talk
There is a talk switch in each
output fast strip and also on the
output ‘overview’ displays in the
GUI channel strip.
If the TALK/[TLK] switch in the
talk mic section is active, the
talk buttons will illuminate to
prompt the operator to select a
bus that the talk signals should
be routed to. These are also
used to set up a talk group after
pressing one of the talk/osc
routing panel buttons.
Dynamics and EQ
The control surface has a combined dynamics and EQ section that contains DYN and
EQ on/off buttons, and a listen LED (yellow) that illuminates when listen is active in
the output processing area to show when a channel has its dynamic side chain soloed.
In the GUI channel strip overview display the aux, matrix and master outputs each
have a compressor section and an EQ section (both are highlighted in the diagram
below). Return outputs only have an EQ section. Clicking within either of these
sections will open their respective processing areas, which are described in the
following subsections.
Figure 39: Dynamics and EQ areas for the output channels on the control surface and
GUI
