Talk mic 155
PRO Series Live Audio Systems
Owner’s Manual
The three control knobs are used in conjunction with mic XLRs (in the screen housing
and the rear connector panel) and the two TALK routing switches (internal and
external).
>> To select the internal talk mic
1 In the talk mic section of the master bay, press TALK (internal) to switch in the
talk mic section (see “Talk mic” on page 154).
2 In the source a or source b section of the master bay, press TALK. Your
chosen section will determine which system bus (A or B) the talk mic will be
sourced from (see “Monitor output (a and b) sections” on page 147 and “source
(a and b) sections” on page 148).
External talkback
The external talkback input is a mic/line input at the stage end of the system that,
when enabled in the monitor section (see “Monitor output (a and b) sections” on
page 147), can mix onto the local monitor outputs.
4 limiter control
knob
Gives continuous adjustment of the peak limiter value
from 0dB to +20dB.
5 mic gain control
knob
Provides continuous mic amplifier gain adjustment of
the mic connected to mix bay control surface. Range
is +15dB to +60dB and operates in conjunction with
the peak limiter.
6 Talk patching
sections.
See Table 25 “Navigating to the Patching screen” on
page 418.
Item Element Description
