311
PRO Series Live Audio Systems
Owner’s Manual
Chapter 31: Outputs
This chapter shows you the areas on the control surface that are used to manage the
outputs and also describes their function. There are four type of output: auxes,
returns, matrices and masters.
The structure of this chapter is loosely based on the signal path of the output channels
and also the processing areas, which are opened via the output channel overview
displays in the GUI channel strip.
Output channel routing
The following table shows the approximate signal path of each output type.
* Order can be swapped (see “Processing order” on page 329).
# Includes side chain section.
Channel controls Aux Return Matrix Master
Configuration See
page 327
See
page 327
See
page 327
See
page 327
Direct input See
page 328
N/A See
page 328
See
page 328
*#Dynamics (dual
compressor)
See
page 320
N/A See
page 320
See
page 320
Insert See
page 329
N/A See
page 329
See
page 329
*EQ See
page 321
N/A See
page 321
See
page 321
Mixes Matrix sends
only (see
page 329)
Matrix sends
only (see
page 329)
N/A N/A
Master controls,
solo select and
fader
See
page 330
N/A See
page 330
See
page 330
