66 Chapter 7: Navigation
PRO Series Live Audio Systems
Owner’s Manual
Navigating the output channels
The output channels comprise auxes, returns, matrices and masters.
Figure 12: Output channel navigational controls
Item Element(s) Description
1 Quick access
button — master
channels
Quickly selects the local master channel. Illuminates
(blue) when active.
2 Quick access
button — output
fast strip
Quickly selects the local output channel. Illuminates
(blue) when active.
