About the crossfade Edit Event window 229
PRO Series Live Audio Systems
Owner’s Manual
Using a crossfade mute
The Mute option of the Parameters list lets you initiate a mute at the end of a
crossfade down operation. For example, if you set a crossfade of two seconds, the
mute will turn on after this time has expired (provided it was off). If the crossfade is a
‘crossfade up’, the mute will turn off during the crossfade up time (provided it was on).
Crossfade set up section in the Edit Event window
The crossfade set up section (bottom of the Edit Event window) is where you set up
how the crossfade operates. Here you can set up the duration of the crossfade and the
rate at which it occurs. You can configure two crossfade rates per crossfade or keep its
rate constant throughout.
Figure 26: Crossfade set up section
8 LFE level control
knob
Sub
9 MUTE switch Mute
Item Element Function
1 % of Travel
number field
Sets the initial travel distance of the control as a
percentage of the total distance of travel.
2 % of Time
number field
Sets the time for the initial travel of the control as a
percentage of the overall time.
3 Faders Down field Sets the time taken for the total travel (milliseconds)
of the control for a ‘fader down’ (or whichever control
is used) crossfade event. For the Faders Up field,
this sets the time taken for the total travel
(milliseconds) of the control for a ‘fader up’ crossfade
event.
4 Faders down
section
For setting the crossfade down parameters.
5 Faders up section For setting the crossfade up parameters.
6 Graph Up/down crossfade graph.
Item Control Parameter option
