PRO Series general specifications
Sampling frequency 96kHz
Latency delay <2ms input to master (no compensation)
Dynamic range 110dB, 22Hz to 22kHz (no pre-emphasis)
Maximum voltage gain 80dB inputs to subgroups and masters
86dB inputs to aux and matrix
Crosstalk at 1kHz -100dB physically adjacent input channels
Crosstalk at 10kHz -100dB physically adjacent input channels
Fader/pan cut off at 1kHz -100dB
Fader/pan cut off at 10kHz -100dB
Display screens 2 x 15” daylight-viewable colour screens
LCD switch 33 x RGB colour
Motorised faders 29 x touch-sensitive
Fader resolution 1024 steps
Encoders 102 x touch-sensitive
Encoder resolution 512 steps
Dimensions PRO Series Control Centre: 1300 x 1000 x
400 mm
DL251 I/O Box: 5U x 410 mm deep
DL351 I/O Box: 7U x 410 mm deep
DL371 DSP: 7U x 410 mm deep
DL451 I/O Box: 3U x 410 mm deep
Net weight (standard install) PRO3:
Control centre: 120 kg
1 x DL251: 10 kg
1 x DL371: 30 kg
Total: 160 kg
PRO6:
Control centre: 120 kg
1 x DL351: 50 kg
1 x DL371: 30 kg
Total: 200 kg
PRO9:
Control centre: 120 kg
1 x DL351: 50 kg
1 x DL371: 30 kg
1 x DL451: 13 kg
Total: 213 kg
Power requirements 100V to 240V, 50 to 60Hz
Operating temperature range +5°C to +40°C
Storage temperature range -20°C to +60°C
