350 Appendix B: Technical Specification
PRO Series Live Audio Systems
Owner’s Manual
Typical configuration
(assuming all analogue I/O)
I/O Box mic/line inputs (XLR)
Surface mic/line auxiliary inputs
Total mic input count
8 x (XLR) I/O box master/matrix
outputs
8 x (Jack) Surface aux/group outputs
8 x (Jack) Surface assignable inputs
8 x (Jack) Surface assignable outputs
1 x (XLR) Surface stereo master
output
2 x (XLR) Surface stereo monitor
outputs
48
8
56
56
8
64
80
8
88
System expansion
(optional rack boxes)
Multiple 3U rack configurable I/O
boxes can be connected that house
24 x I/O slots in 8 x 8 wide blocks of:
8 x (XLR) mic/line inputs or
8 x (XLR) line outputs or
8 x (Jack) line in and 8 x line out
4 x (stereo) AES3 in and 4 x (stereo)
AES3 out
UUU
Multiple 5U rack fixed configuration
I/O boxes that house:
48 x (XLR) mic/line inputs
16 x (XLR) outputs
UUU
Multiple 6U rack Splitters house
96 x Splitter mic/line inputs
2 x 96 Splitter outputs
1 x 96 transformer isolated Splitter
outputs
UUU
Input audio processing Dual slope high and low pass filters
4-band parametric EQs (includes 8
returns) with 3 shelf modes
4-mode creative input compressors
Input gates
48
56
48
48
56
64
56
56
80
88
80
80
Mix/output audio processing Output 5-band parametric EQ with
shelf and multiple high and low pass
modes
5-mode creative output dynamics
Assignable Klark Teknik output GEQs
27
27
8
35
35
8
35
35
8
Assignable audio processing 8 x assignable stereo effects
(each can be reconfigured to generate
4 additional GEQs, making a total of
36 available on the control centre)
UUU
Mixing control assistance 8 x auto-mutes
6 x surface population groups
10 x VCA faders
10 x VCA associated population
groups
1000-scene snapshot automation
UUU
Resilience N+1 and fault tolerant modular
system with dual redundant system
interconnections
UUU
Item Item
PRO3
PRO6
PRO9
