Matrix send
The following diagram details the scoped parameters of the return channels. Although
it only shows matrix buses 1 to 8, it also applies to matrix buses 9 to 16 (PRO6 and
PRO9 only).
ABC D EFG H
Item Parameter
1 Send level N/A Yes N/A N/A N/A Yes N/A N/A
2 Send pan
N/A Yes N/A N/A N/A Yes N/A N/A
3 Send pre-fader on/off
N/A Yes N/A N/A N/A Yes N/A N/A
4 Send on/off
N/A Yes N/A N/A N/A Yes N/A N/A
D
F
G
H
B
C
A
4
3
4
3
1/2
4
3
4
3
1
Matrix buses
processing
area in GUI
channel strip
