Midas PRO SERIES

228 Chapter 23: Crossfades (Automation)
PRO Series Live Audio Systems
Owner’s Manual
About the crossfade parameters
The following diagram shows the PRO Series configured for 5.1 surround mode, which
utilises each available parameter option. The presence of the divergence, centre
level and LFE level sections are dependent on the currently selected surround mode.
3 Parameter drop-
down list
For choosing the level control that you want the
crossfade to operate on (see “About the crossfade
parameters” on page 228).
4 Crossfade Group
drop-down list
Contains all of the available user-configured
crossfade groups. Also includes the default example
group that contains all possible crossfade sources.
Item Control Parameter option
1 Fader Fader
2 pan control knob Pan
3 mono level/SIS
image/[fb pan]
control knob
image/front back
4 front control knob Front Div
5 back control knob Rear Div
6 front to back control
knob
F-R div
7 centre level control
knob
Centre
Item Element Description
input channel
overview in GUI
channel strip
2
1
Masters processing
area in GUI
channel strip
3
2
23
1
2
3
GUI input
fast strip
2
9
9
4
6
5
7
8
