Solo system 145
PRO Series Live Audio Systems
Owner’s Manual
Delay (GUI only)
You can delay each monitor output signal (A and B) individually by up to
500 milliseconds (ms). This is done via the two delay sections in the Monitors screen.
This function does not have support on the control surface.
Monitor A and B delay sections on the GUI
Solo system
solo a and solo b system sections allow solo signals to be selected independently for
each monitor system (A and B). These can be selected as AFL (PFL extinguished), PFL
(PFL illuminated), additive (ADD enabled) or interlock cancelling.
The monitor outputs can be configured for different uses:
•normal
• dual operation
• LCR monitor
• broadcast
•user defined
Each of these modes changes the interleaving logic between differing areas of the
monitor output. A mode select button scrolls through the possible options.
Additionally, there is a solo in place switch for activating the SIP function.
10 MUTE button This is a headphones mute button that mutes the
headphone jack.
11 Control knob Adjusts headphones level, in the range infinity (∞) to
+10dB.
Item Element Description
1 Control knob Adjusts the monitor output signal delay in the range
0ms to 500ms.
2 Up/down spin
buttons
Provide finer adjustment of the monitor output signal
delay.
3 ON switch Switches the delay on/off.
4 Two delay value
fields
Show the current delay value in milliseconds (ms)
and metres (m).
Item Element Description
