Surround panning 135
PRO Series Live Audio Systems
Owner’s Manual
Although the position cursor changes automatically according to the adjustment
of the surround panning controls, you can also adjust it on the GUI using drag.
The following table shows the fader parameters with None selected as on/off in the
Surround Mode section of the Preferences screen (see “Setting the configuration
preferences” on page 249).
Table 9: Fader parameters with surround panning on/off
Item Description
1 fb pan control knob, moves position cursor in spatial diagram up/down.
2 Left-centre-right control knob, moves position cursor in spatial diagram
left/right.
3 front control knob, adjusts the divergence of the front speakers.
4 front to back control knob, adjusts the divergence of the front and rear
speakers.
5 back control knob, adjusts the divergence of the rear speakers.
6 centre level control knob, adjusts the divergence of the centre speaker.
7 LFE level control knob, adjusts the signal level of the LFE (usually a
subwoofer).
Parameter None mode off None mode on Notes
Level (fb pan) Yes Yes If left or right
channel has SIS
on, level is image
(below).
In other surround
modes, it is
front/back pan
(below).
Image (fb pan) Yes Yes See above
Pan Yes Yes See above
Divergence (front
to back)
Yes N/A N/A
Divergence (front) Yes N/A N/A
Divergence (back) Yes N/A N/A
Centre level Yes N/A N/A
LFE level Yes N/A N/A
