326 Chapter 31: Outputs
PRO Series Live Audio Systems
Owner’s Manual
Item Control Function
1 MUTE switch Mutes all post-processing signals leaving the channel.
(In addition to scene recall, muting can be remote
from the auto-mute masters.)
2 LEDs These safe LEDs illuminate when their associated safe
is on.
3 level control knob Adjusts the output signal level. In the masters
section (master bay), this is a fader.
4 SOLO switch Activates signal routing to the monitor A section of
the control centre.
5 FADER/[FDR]
switch
Switches fader safe on, so that the fader is removed
from scene recall.
6 MUTE/[MTE]
switch
Switches mute safe on, so that mute is removed from
the scene recall and auto-mute action.
7 AUTO/[AUT]
switch
Switches auto safe on, so that the channel is removed
from scene recall (this does not affect the action of
the auto-mutes and VCA control groups) and control
is removed from VCA control group faders.
8 Fader Adjusts output signal level. Has the same function as
the level control knob (see item 3).
9 B switch (GUI
only)
This solo B switch changes the operation of the SOLO
switch so that it routes signals to the Monitor B
section of the control centre.
10 Meter Output signal level meter.
11 Red on/off
indicator
Illuminates when mute is on.
12 Blue on/off
indicator
Illuminates when solo B is on.
13 Yellow on/off
indicator
Illuminates when solo on.
