428 Appendix K: Parameters Affected By Scope

PRO Series Live Audio Systems

Owner’s Manual

The following diagram details the scoped parametric EQ parameters of the input

channels.

ABCDE F G H

Item Parameter

1 All filters: freq, gain,

width, SHAPE

N/A Yes N/A Yes N/A N/A N/A N/A

2 EQ in/out

N/A Yes N/A Yes N/A N/A N/A N/A

input channel

overview in GUI

channel strip

EQ processing

area in GUI

channel strip

Main Page
