544 Appendix O: Parameters Affected By Stereo Linking
PRO Series Live Audio Systems
Owner’s Manual
Note: The compressor and gate sidechains of stereo paired channels are always linked
such that they ensure the same amount of gain reduction is applied to both channels.
12 ON/[GTE] switch Gate on/off
13 threshold control
knob
Gate threshold
14 release control knob Gate release
15 attack control knob Gate attack
16 ratio/range/[range]
control knob
Gate range
17 hold control knob Gate hold
18 IN switch Gate sidechain in/out
19 freq control knob Gate sidechain frequency
20 WIDTH pushbutton Gate sidechain width (unlabelled) selector: 2 Oct,
1 Oct and 0.3 Oct
Item Control Parameter
