27 - 9
27.6.3 The AG Tab
27.6.4 The Other Tab
Zero
/
Select this button to start zeroing the CO
2
module.
Menu Item Default Setting Description
Menu Item Default Setting Description
Zero Recovery for 30s On After the zero calibration is completed, the AG
module reacquires the AG readings.
•
On: During the reacquisition period, “Zero
Recovering
” is displayed in the AG numeric
area.
•
Off: During the reacquisition period, “Zero
Recovering
” is not displayed in the AG
numeric area.
Types of Gas Measurement All Selects what gases are detected. If any gas is
deselected, it will not be displayed or used for
calculating the MAC value. When the
concentration of the unselected gas is equal to or
greater than 1%, you will be prompted to select
the gas to enable the measurement (
Set XX
measurement to On
).
Zero
/
Select this button to start zeroing the AG module.
Menu Item Default Setting Description
IBP Filter 12.5 Hz /
PAWP Timeout 15 min The measurements become outline fonts after a
preset time. This avoids older values being
misinterpreted as current measurements.
C.O. Timeout 15 min
NIBP Timeout 15 min
CO2 Flow Rate For Neo (for Sidestream CO
2
Module Without O
2
)
90 ml/min Selects flow rate when using the sidestream CO
2
without the O
2
monitoring function to monitor a
neonatal patient.
Outline Font for Suspected Values On Selects whether unreliable HR, SpO
2
, and BIS
measurements are displayed in outline font. This
prevents unreliable measurements from being
misinterpreted as normal measurements,
