28 - 3
6. Close the battery door.
28.3.3 Installing the Battery in a External Battery Compartment
For ePM 12M/ePM 12MA/ePM 12MC, besides the built-in battery compartment, you can also use a smart battery
by connecting an external battery compartment.
The external battery compartment must only be installed by service personnel trained and authorized by
Mindray. To install the battery, contact your service personnel.
To install the smart battery into the external battery compartment, follow this procedure:
1. Turn off the monitor. Disconnect the power cable and other cables.
2. Place the monitor on the worktable with monitor face down.
3. Pull up the battery door to open the battery compartment as indicated below.
4. Insert the battery into the battery compartment. Push the battery downwards till the battery terminal is
plugged into the battery connector.
5. Close the battery door.
28.4 Battery Indications
The battery LED, on-screen battery power indicator and related alarm messages indicate the battery status.
28.4.1 Battery LED
The battery LED indications are as follows:
■ Green: the battery is fully charged.
■ Yellow: the battery is being charged.
■ Green and flashing: the monitor runs on battery power.
■ Off: no battery is installed, or the battery malfunctions, or the AC mains is not connected when the monitor
is powered off.
28.4.2 Battery Power Indicators
The on-screen power indicator indicates the battery status as follows:
■ indicates that the battery works correctly. The green portion represents the remaining charge.
■ indicates that the battery power is low and needs to be charged.
■ indicates that the battery is almost depleted and needs to be charged immediately. Otherwise,
the monitor will soon automatically shut down.
■ indicates that the battery is being charged.
■ indicates that no battery is installed or the battery fails.
