28 - 2
• Lithium batteries replaced by inadequately trained personnel could result in a hazard (such as
excessive temperatures, fire or explosion).
• Only the smart rechargeable lithium-Ion battery can be installed in the external battery
compartment.
• Ensure that compatible batteries are used for your monitor. For more information, see
28.3.1Identifying the Battery Type. Otherwise, the monitor may be damaged or cannot work
properly.
28.3.1 Identifying the Battery Type
The smart battery label is used to distinguish the battery type. The smart battery has this label, while
the non-smart battery does not have it.
Not all the battery types are applicable for your monitor. You can only use a smart battery if the smart battery
label is available on the back of the battery compartment and a non-smart battery if the smart battery label is
not available.
The following figure shows the smart battery label on the back of the battery compartment
28.3.2 Installing the Battery in a Built-in Battery Compartment
No battery is installed when the monitor leaves the factory. The battery must only be installed by service
personnel trained and authorized by Mindray. To install the battery, contact your service personnel.
To install the battery, follow this procedure:
1. Turn off the monitor. Disconnect the power cable and other cables.
2. Open the battery door as indicated below.
3. Turn the latch aside.
4. Insert the battery into the battery compartment with the battery terminal inwards.
5. Turn the latch back to the middle position.
To Next Page
