3 - 4
• When removing the module, be careful not to drop it. Always support with one hand while pulling
out with the other.
3.4 Turning on the Monitor
Before turn on the monitor, perform the following inspections:
1. Check the monitor and modules for any mechanical damage. Make sure that all external cables, plug-ins
and accessories are properly connected.
2. Connect the power cord to the power supply.
To turn on the monitor, press the power switch.
When the monitor is turned on, the alarms are paused for two minutes. Then the alarm system is activated.
• Check that visual and auditory alarm signals are presented correctly when the equipment is
powered on.
• Do not use the monitor on a patient if you suspect it is not working properly, or if it is mechanically
damaged. Contact the service personnel or Mindray.
3.5 Operation and Navigation
Everything you need to operate the monitor is on its screen. Almost every element on the screen is interactive.
Screen elements include parameter values, waveforms, quick keys, information fields, alarms fields and menus.
Often you can access the same element in different ways. For example, you can access a parameter menu by
selecting corresponding numeric area or waveform area, through the Menu hard key on the parameter
module, or through the Parameters Setup quick key.
3.5.1 Using the Touchscreen
You can touch the screen or swipe across the screen with your fingers to operate the monitor.
3.5.1.1 Tapping or Swiping across the Screen
â– Tapping the screen
â—† To select an item from menus or lists, or select a quick key, tap on it with your finger.
â—† To enter a parameter menu, tap corresponding numeric area or waveform area. For example, select
the ECG numeric area or waveform area to enter the ECG menu.
â– Swiping across the screen with a single finger
â—† To scroll through a list and a menu, swipe up and down.
â—† To show or expand the Minitrends screen or the EWS screen, swipe right across the corresponding
screen.
â—† To contract or hide the Minitrends screen or the EWS screen, swipe left across the corresponding
screen.
â– Swiping across the screen with two fingers
â—† To switch to another screen, swipe left or right across the screen. For example, on the normal screen,
swipe with two fingers from left to right to switch to the Minitrends screen.
â—† To discharge a patient, swipe from top to bottom.
3.5.1.2 Locking the Touchscreen
To avoid misuse, you can temporarily disable the touchscreen. To do so, hold and press the Main Menu quick
key and slide as directed by the arrow. A padlock symbol displays at the top of the main menu quick key if
the touchscreen is disabled.
