3 - 8
3.6.2 Menus
All menus have similar style and structure, see the figure below:
3.6.3 Quick Keys
The monitor provides quick keys for you to quickly access some functions. The quick key area is located at the
bottom of the screen. The Main Menu key is permanently located the right bottom, and the More key is
permanently located at the left bottom. Selecting the More quick key shows more quick keys. The quick keys
displayed on the screen are configurable.
(1) Menu heading
(2) Submenu tabs
(3) Operation buttons
(4) Exit button: closes the current menu page.
(5) Main body area: includes menu items and options.
(6) Switch:
â—† Green: the switch is on.
â—† Gray: the switch is off.
