E - 3

For BF applied parts

◆ 100 A in Normal Condition

◆ 500 A in Single Fault Condition

E.7 Mains on Applied Part Leakage

The Mains on Applied Part test applies a test voltage, which is 110% of the mains voltage, through a limiting

resistance, to selected applied part terminals. Current measurements are then taken between the selected

applied part and earth. Measurements are taken with the test voltage (110% of mains) to applied parts in the

normal and reverse polarity conditions

The following outlet conditions apply when performing the Mains on Applied Part test.

■ Normal Polarity;

■ Reversed Polarity

LIMITS

◆ For CF applied parts: 50 A

◆ For BF applied parts: 5000 A

E.8 Patient Auxiliary Current

Patient Auxiliary currents are measured between any selected Applied Part connector and the remaining

Applied Part connector s. All measurements may have a true RMS only response.

The following outlet conditions apply when performing the Patient Auxiliary Current test.

■ normal polarity (Normal Condition);

■ reverse polarity (Normal Condition),

■ normal polarity with open neutral (Single Fault Condition);

■ reverse polarity with open neutral (Single Fault Condition).

■ normal polarity with open earth (Single Fault Condition);

■ reverse polarity with open earth (Single Fault Condition).

LIMITS

For CF applied parts,

◆ 10 A in Normal Condition

◆ 50 A in Single Fault Condition

For BF applied parts,

◆ 100 A in Normal Condition

◆ 500 A in Single Fault Condition

NOTE

• Make sure the safety analyzer is authorized comply with requirement of IEC60601-1.

• Follow the instructions of the analyzer manufacturer.
